Y-splitter, M12, female, straight, 4 poles, with open cable end
Product description
Product type: with cable outlet
Application: Sensor/actuator
Item description: YK-FK4M12-10/10/S7400
Item-No.: 8075701
Cable quality: S7400, PUR, robotic, UL
Cable length:
Packaging unit: 1 pcs
Certifications
Product details
| Technical data | Exit 0 | Exit 1 | Exit 2 |
|---|---|---|---|
| Ambient temperature product | -30°C...+90°C | - | - |
| Coding of | A | - | - |
| Connector | Female, M12, straight | Open cable end | Open cable end |
| Contact material | Metal, CuZn, gold-plated | - | - |
| Contact-carrier material | Plastic, TPU, BK | - | - |
| Coupling nut material | Metal, CuZn, nickel-plated | - | - |
| Current load (at 40°C) | 4 A | - | - |
| Degree of pollution | 3 | - | - |
| Degree of protection (mounted) | IP65, IP67, IP68 | - | - |
| Grip body material | Plastic, TPU, BK | - | - |
| Insulation resistance |
|
- | - |
| Mechanical life-cycle | >100 mating cycles | - | - |
| Number of pins | 4 | - | - |
| Rated voltage |
|
- | - |
| Resistance | 5 mΩ | - | - |
| Sealing (female) material | FPM/FKM | - | - |
| Standards | IEC 61076-2-101 | - | - |
Flexible, silicone- and halogen free control cable with high mechanical strength. Due to its outstanding properties in drag-chain adaption, torsionresistance and weld-field immunity, it is very well suited for the flexible applications in robotics, handling- and assembly technology as well as machine tools. The cable meets the UL and CSA (UL10493/20549; cULus) requirements.
| Technical data | |
|---|---|
| Bending radius (fixed) | 5 x Ø-cable |
| Bending radius (repeated) | 10 x Ø-cable |
| Cable quality | S7400, PUR, robotic, UL |
| Cable-jacket material | PUR |
| Drag chain-application | ≥ 10 Mio. cycles |
| Halogen-free | Yes |
| Jacket color | OG, similar RAL2003 |
| Outer diameter of jacket | 4.80 mm |
| Rated voltage cable | ≤300 V |
| Special features | Flame retardant, halogen free, hydrolysis proof, LABS free, oil resistant, ozone resistant, recyclable, RoHs compliant, acid- and alkali resistant, drag chain-adapted, welding sparks resistant, seawater resistant, silicone free, torsion resistant, UV resistant |
| Temperature range (drag chain) | -25°C…+60°C |
| Temperature range (fixed) | -40°C...+90°C |
| Temperature range (repeated) | -30°C...+90°C |
| Torsion | +/-360°/m, ≥ 10 Mio. cycles |
| Wire colors | BN, BU, BK |
| Wire cross-section | 3 x 0.34 mm² |
| Wire insulation material | PP |
| Wire structure | 42 x 0.10 mm |
