Y-splitter, M12, female, straight, 4 poles, with cable outlet, M12, male, straight, 3 poles, M12, male, straight, 3 poles
Product description
Product type: with cable outlet
Application: Sensor/actuator
Item description: YK-FK4M12-2AL-WAS3-5/5/P00
Item-No.: 8076021
Cable quality: P00, PVC
Cable length:
Packaging unit: 1 pcs
Certifications
Product details
| Technical data | Exit 0 | Exit 1 | Exit 2 |
|---|---|---|---|
| Ambient temperature product | -30°C...+90°C | - | - |
| Coding of | A | A | A |
| Connector | Female, M12, straight | Male, M12, straight | Male, M12, straight |
| Contact material | Metal, CuZn, gold-plated | Metal, CuSn, gold-plated | Metal, CuSn, gold-plated |
| Contact-carrier material | Plastic, TPU, BK | Plastic, TPU, BK | Plastic, TPU, BK |
| Coupling nut material | Metal, CuZn, nickel-plated | Metal, CuZn, nickel-plated | Metal, CuZn, nickel-plated |
| Current load (at 40°C) | 4 A | 4 A | 4 A |
| Degree of pollution | 3 | - | - |
| Degree of protection (mounted) | IP65, IP67, IP68 | - | - |
| Grip body material | Plastic, TPU, BK | - | - |
| Insulation resistance |
|
- | - |
| Mechanical life-cycle | >100 mating cycles | - | - |
| Number of pins | 4 | 3 | 3 |
| Rated voltage |
|
|
|
| Sealing (female) material | FPM/FKM | - | - |
| Standards | IEC 61076-2-101 | - | - |
PVC-cable for measurement and control-, and sensor technology. Suitable for applications in dry areas on packaging machines, assembly- and conveyor technology. High flexibility with unstressed movement (conditional drag-chain application possible). Predestined for applications in food- and beverage industry.
| Technical data | |
|---|---|
| Bending radius (fixed) | 5 x Ø-cable |
| Bending radius (repeated) | 10 x Ø-cable |
| Cable quality | P00, PVC |
| Cable-jacket material | PVC |
| Jacket color | GY, similar RAL7040 |
| Outer diameter of jacket | 4.20 mm |
| Rated voltage cable | ≤300 V |
| Special features | Good resistance against oils and chemicals, LABS free, ozone resistant, recyclable, RoHs compliant, acid- and alkali resistant, seawater resistant, UV resistant |
| Temperature range (fixed) | -25°C...+80°C |
| Temperature range (repeated) | 0°C...+80°C |
| Wire colors | BN, BU, BK |
| Wire cross-section | 3 x 0.34 mm² |
| Wire insulation material | PVC |
| Wire structure | 19 x 0.15 mm |
